BorgWarner (BERU) - PSG007-BEU - Glow Plug

Utility numbers 0 103 110 008 E2520028814A1 PSG007 SA017015 03L905061K 03L905061G. Characteristics Glow Plug Design after-glow capable Pencil-type Glow Plug Voltage [V] 4,4 V Connector type 4 mm PIN (PSG) Length [mm] 149,0 mm Fitting Depth [mm] 28,0 mm Thread Size M10x1,0 Spanner Size 12 mm Cone Pitch 63 Tightening torque from [Nm] 15 Nm Tightening torque to [Nm] 20 Nm Failure Moment [Nm] 35 Nm Supplementary Article/Info 2 with pressure sensor. Replacement numbers Item replaces Glow Plug - PSG002 Glow Plug - PSG008. OE numbers Audi 03L905061D 03L905061E 03L905061F 03L905061G 03L905061H 03L905061K 03L905061L 03L905061M 059905061E 059905061H SEAT 03L905061F 03L905061G 03L905061H 03L905061K 03L905061L 03L905061M 059905061E 059905061H Skoda 03L905061F 03L905061G 03L905061H 03L905061K 03L905061L 03L905061M 059905061E 059905061H VAG 03L 905 061 D 03L 905 061 E 03L 905 061 F 03L 905 061 G 03L 905 061 K 03L905061L VW 03L905061D 03L905061E 03L905061F 03L905061G 03L905061H 03L905061K 03L905061L 03L905061M 059905061E 059905061H. Graphic Preview
