Dealer part number G16497-MOR
Part Number G16497
Parts Description MONROE ORIGINAL (Gas
Technology)
Packing unit 1
Quantity per PU 1
Parts state Normal
EAN 5412096518249
Characteristics
Shock Absorber Type Gas Pressure
Shock Absorber Design Suspension Strut
Shock Absorber System Twin-Tube
Shock Absorber Mounting Type Top pin
Bottom Clamp
Weight [kg] 4,000 kg
Bore Diameter [mm] 32 mm
Observe technical data
Length 1 [mm] 391 mm
Length 2 [mm] 553 mm
Guarantee 5 years guarantee with accessories when replaced in pairs
Piston Rod Diameter [mm] 22 mm
Article number of recommended accessories MK194
PK163
Packaging length [cm] 51,5 cm
Packaging width [cm] 16,2 cm
Packaging height [cm] 16,2 cm
Housing diameter in clamping area [mm] 55 mm
OE numbers
Audi: 1K0413031AQ, 1T0413031CC, 1T0413031CP, 1T0413031DA, 1T0413031DB, 1T0413031ET, 1T0413031HG, 317578
5ND413031B, 5N0413031AE, 5N0413031AF, 5N0413031AR
SEAT: 1T0413031EQ, 1T0413031HP
Skoda: JZW413031A, 1T0413031CJ, 1T0413031CK, 1T0413031CL, 1T0413031CM, 1T0413031CN, 1T0413031CS,
1T0413031DL, 1T0413031DN, 1T0413031DP, 1T0413031DQ, 1T0413031DR, 1T0413031DS, 1T0413031FD,
1T0413031FK, 1T0413031FL, 1T0413031FM, 1T0413031FN, 1T0413031HK, 1T0413031HL, 1T0413031HM,
1T0413031HN, 1T0413031HP, 1T0413031JD, 3AA413031M, 3C0413031AA, 3C0413031AB, 3C0413031AM,
3C0413031AN, 3C0413031AQ, 3C0413031AS, 3C0413031AT, 3C0413031BA, 3C0413031BB, 3C0413031M,
3C0413031N, 3C0513049CR
MONROE - G16497-MOR - Shock Absorber 20.11.2024
Page 1 From
7
OE numbers
VAG: 1T0413031CJ, 1T0413031CK, 1T0413031DH, 1T0413031DL, 1T0413031DN, 1T0413031DP, 1T0413031DQ,
1T0413031DS, 1T0413031FS, 1T0413031GG, 1T0413031GH
VW: JZW413031A, 1T0413031AS, 1T0413031AT, 1T0413031BA, 1T0413031BB, 1T0413031BC, 1T0413031BP,
1T0413031BQ, 1T0413031BR, 1T0413031BS, 1T0413031BT, 1T0413031CA, 1T0413031CB, 1T0413031CJ,
1T0413031CK, 1T0413031CL, 1T0413031CM, 1T0413031CN, 1T0413031CS, 1T0413031DH, 1T0413031DL,
1T0413031DM, 1T0413031DN, 1T0413031DP, 1T0413031DS, 1T0413031DT, 1T0413031EG, 1T0413031EH,
1T0413031EM, 1T0413031EQ, 1T0413031FA, 1T0413031FB, 1T0413031FD, 1T0413031FK, 1T0413031FL,
1T0413031FM, 1T0413031FN, 1T0413031FS, 1T0413031FT, 1T0413031GA, 1T0413031GG, 1T0413031GH,
1T0413031GJ, 1T0413031GK, 1T0413031GN, 1T0413031GP, 1T0413031GQ, 1T0413031GR, 1T0413031HH,
1T0413031HJ, 1T0413031HK, 1T0413031HL, 1T0413031HM, 1T0413031HN, 1T0413031HP, 1T0413031HQ,
1T0413031HR, 1T0413031HT, 1T0413031JA, 1T0413031JN, 1T0413031JQ, 1T0513031GB, 1T0513031GC,
2K5413031, 3AA413031M, 3C0413031AA, 3C0413031AB, 3C0413031AF, 3C0413031AG, 3C0413031AH,
3C0413031AJ, 3C0413031AM, 3C0413031AN, 3C0413031AQ, 3C0413031AS, 3C0413031AT, 3C0413031BA,
3C0413031BB, 3C0413031H, 3C0413031J, 3C0413031L, 3C0413031M, 3C0413031N, 3C0513031L, 3C0513049CR,
5C0413031AK, 5C0413031AL, 5C0413031BA, 5C0413031BB, 5C0413031BD, 5C0413031BE, 5C0413031BK,
5C0413031BL, 5C0413031BN, 5C0413031BQ, 5C0413031CS, 5C0413031CT, 5C0413031DG, 5C0413031E,
5C0413031M, 5C0413031P, 5C0413031Q, 5C0413031R, 5C0413031T, 5N0413031AA, 5N0413031AC, 5N0413031AD,
5N0413031AH, 5N0413031AJ, 5N0413031AK, 5N0413031AL, 5N0413031AM, 5N0413031K, 5N0413031L, 5N0413031T
MONROE - G16497-MOR - Shock Absorber 20.11.2024
Page 2 From
7
Images
MONROE - G16497-MOR - Shock Absorber
