Dealer part number 0332019150-BOC
Part Number 0 332 019 150
Packing unit 1
Quantity per PU -
Parts state Normal
EAN 3165141686050
Characteristics
Combi Switch Function Normally Open Contact
without light dimmer function
Current Strength [A] 30 A
Voltage [V] 12 V
Number of pins 5 terminal
Relay function Normally open contact
Housing Type Synthetic Material Housing
Temperature range from [°C] -40 °C
Temperature range to [°C] 100 °C
Housing Colour black/grey
Supplementary Article/Supplementary Info with holder
Resistor [Ohm] 16 Ohm
Utility numbers
0 332 209 150, 4RD933332051, 4RD933332401, 76705Z
Replacement numbers
0 332 003 017, 0 332 003 021, 0 332 003 021, 0 332 003 021, 0 332 003 023, 0 332 003 023, 0 332 003 027, 0 332 003
027, 0 332 019 165, 0 332 019 165
OE numbers
AGRIFAC: 7764767
Alfa Romeo: 116 00 65 135 03, 530623, 531417
Audi: 141 951 253 A, 311 906 061 C, 311 963 141 B
Auto Union: 6617 330 75 00 250, 6842 386 03 00 016
BMW: XX XX 9 059 177, 09059177, 61 31 1 351 317, 61 31 1 352 156, 61 31 1 353 361, 61 31 9 059 177
CASE IH: 820 044 63
Citroën: DX 524 101 A, 5 414 209, 5 422 133
DAF: 261062, 501945, 504945
DEUTZ-FAHR: 01164015
BOSCH - 0332019150-BOC - Relay, main current 27.01.2025
Page 1 From
6
OE numbers
FAUN: 1731 009, 1731 103, 1731 158
FENDT: X 830 250 010, X 830 250 010 000, 3539335M92, 359 819 8M1, 3906604M1, 656 108 302, 72380976
Ferrari: 138075
Fiat: 4339371, 82277344, 9268140
Ford: D7NN 14N089 A, F1NN 14N089 AA, 13A025H, 636 263, 82DB 11390 AA
HANOMAG: 3598 198 M1
HANOMAG RHEINSTAHL: 1 534 935 301, 533 935 101, 534 935 301
HENSCHEL: 0 921 332
Hyundai: 95225-3B100
Iveco: 4320625, 4320629, 7686773
JOHN DEERE: AZ 26 996
KÄSSBOHRER: 7 375 031 000
KHD: C 12V H7606, 01161137, 01164015, 01169077, 04323132, 06258834, 116 1137, 116 4015, 116 9077, 432 3132,
625 8834
Kia: 0K900 18811
Lancia: 4339371, 82277344, 9268140
Lotus: B089M6057F
MAN: 81 25902 0059, 81 25902 0446, 81 25902 7009, 90 81616 0332
MASSEY FERGUSON: 3539 335 M92
Mercedes-Benz: A 000 542 15 19, A 000 542 81 19, A 000 545 80 05, A 001 542 31 19, A 001 542 32 19, A 001 542 43
19, 000 542 15 19, 000 542 81 19, 000 545 80 05, 001 542 31 19, 001 542 32 19, 001 542 43 19
MOTO GUZZI: 12732500, 19732500
MWM: 6 0742 40 6 0005
NEW HOLLAND: 82 004 463
Opel: 03440489, 03445949, 12 38 535, 12 38 609, 12 38 614, 12 38 965, 34 40 489, 90003095
Peugeot: DX 524 101 A, 5 414 209, 5 422 133, 6555 HJ, 6555 VP, 96 730 621 80
Porsche: 0171937503, 141951253B, 171937503, 311963141B, 431951253H
Puch: 700 1 85 101 0
Renault: 77 00 545 853, 77 00 709 633
Saab: 83 76 105, 85 22 310
SCANIA: 21020100, 229542
SEAT: 017 193 750 3, 171 937 503, 4H0 951 253 A
Skoda: 4H0 951 253 A
Steyr: 413 S 08 0031, 990 00 58 0210
TEREX: 0340401494
Vauxhall: 12 38 965, 34 40 489
Volvo: 01235893, 1235893, 239482, 241812, 6211833, 6626921, 6643474, 853544, 870670
BOSCH - 0332019150-BOC - Relay, main current 27.01.2025
Page 2 From
6
OE numbers
VW: 017 193 750 3, 043 195 125 3, 111 963 141 C, 141 951 253 A, 171 937 503, 311 906 061, 311 906 061 C, 311 963
141 B, 4H0 951 253 A, 431 951 253, 431 951 253 A
BOSCH - 0332019150-BOC - Relay, main current 27.01.2025
Page 3 From
6
Images
BOSCH - 0332019150-BOC - Relay, main current
